5L Rotary Evaporator
2.Excellent air tightness, High vacuum performance.
3.PTFE and Viton double sealing.
4.Easy assembling design to be assembled.
5.Double layer cooling coils for improving condensers performance.
6.Supports OEM and ODM.
7.CE, ISO, UL, SGS certification.
8.1 year warranty and quality commitment.
9. PLC fully automatic is optional.
10.Explosion-proof system is optional.
5L Rotary Evaporator - Professional Laboratory Solvent Removal Solution
Our 5L Rotary Evaporator offers the idealize adjust between analytical-scale and industrial-scale handling capabilities. This progressed research facility instrument productively evacuates solvents from tests through dissipation beneath decreased weight, making it perfect for handling medium-volume bunches whereas protecting heat-sensitive compounds. With its pivoting jar plan that increments surface zone and exact temperature control, this item guarantees delicate however viable dissolvable recuperation for your inquire about needs.
Why Choose Our 5L Rotary Evaporator?
Advanced Design Features
Our rotating evaporator joins cutting-edge innovation to provide extraordinary execution. The coordinates plan combines the have unit, radiator, chiller, and vacuum pump into one cohesive framework. You'll advantage from amazing discuss snugness and tall vacuum execution, much obliged to the PTFE and Viton twofold fixing system.
The double-layer cooling coils altogether progress condenser execution, guaranteeing productive vapor capture. The simple gathering plan makes setup and support direct, sparing you profitable time in the research facility.
Superior Technical Specifications
| Parameter | Specification |
|---|---|
| Evaporating Flask Volume | 5L |
| Speed Range | 20-180 RPM |
| Display Type | LED |
| Evaporation Capacity (75% Alcohol) | 2 L/h (Max) |
| Ultimate Vacuum | 9 mbar |
| Timer | YES |
| Temperature Range | Water Bath: 20-100℃, Oil Bath: 20-180℃ (Optional) |
| Temperature Control Accuracy | ±1℃ |
| Heating Power | 2000W |
| Temperature Display | LED |
| Lifting Mode | Motorized |
| Lifting Stroke | 130mm |
| Time Setting Range | 0-999 min |
| Voltage | 220V |
| Frequency | 50/60 Hz |
| Motor Type | Brushless DC Motor |
| Heat Bath | Teflon Coating |
| Protection Class | IP20 |
| Dimensions (D×W×H) | 600×290×720mm |
| Ambient Temperature | 5-40℃ |
| Ambient Humidity | ≤80% |
| Safety Features | Motor overcurrent protection, earth leakage protection, dry heating protection, overheat protection |
Key Performance Advantages
Enhanced Safety and Protection
Your laboratory safety is our priority. The unit features comprehensive protection systems including overheating protection, motor overcurrent protection, and dry heating protection. These safety measures ensure reliable operation and protect both your equipment and samples.
Chemical Resistance and Compatibility
The rotary evaporator demonstrates excellent chemical resistance, making it compatible with a wide range of solvents and samples. It works seamlessly with all ranges of glassware, providing versatility for various applications.
Quiet and Efficient Operation
Experience whole machine shock absorption and noise reduction technology for quieter laboratory operation. This feature is particularly valuable in shared laboratory spaces where noise levels matter.
Easy Maintenance
The design prioritizes easy disassembly and cleaning, making maintenance convenient and efficient. This translates to less downtime and more productive laboratory work.
Professional Applications
This 5L Rotary Evaporator excels in various laboratory applications including:
- Solvent recovery and recycling
- Concentration of solutions
- Extraction processes
- Purification of compounds
- Sample preparation for analysis
The working volume capacity of 2.5L to 3L makes it perfect for medium-scale operations, bridging the gap between smaller analytical units and larger industrial systems.
Quality Assurance and Certifications
WIN Interface STAR Innovation brings 20 a long time of fabricating involvement to each unit. Our items comply with worldwide guidelines counting CE, ISO, UL, and ETL certifications. This guarantees you get gear that meets the most elevated quality and security standards.
Comprehensive Service Support
We give total bolster for your research facility gear needs:
- 24-hour reaction time for specialized inquiries
- 12-month guarantee covering parts and labor
- Complete establishment documentation and guidance
- 12-hour video establishment back for fast setup
Flexible Delivery and Customization
Our coordinates transportation framework underpins ocean cargo, arrive transport, discuss cargo, and express conveyance alternatives. We keep up prepared stock for speedy conveyance to minimize your holding up time.
We get it that diverse research facilities have special necessities. Our ODM/OEM capabilities permit us to customize hardware concurring to your particular needs and territorial measures.
Contact Us
Ready to enhance your laboratory's solvent removal capabilities? Our 5L Rotary Evaporator represents the perfect combination of efficiency, safety, and reliability. With full compliance with international laboratory standards and guaranteed quality, this equipment will serve your research needs for years to come.
For detailed specifications, pricing, or technical consultation, contact our expert team at info@winlinklab.com. We're here to help you select the perfect laboratory equipment solution for your specific requirements.
Experience the difference that professional-grade equipment makes in your laboratory operations. Choose reliability, choose quality, choose WIN LINK STAR TECHNOLOGY.
