Rotary Distiller
2.Excellent air tightness, High vacuum performance.
3.PTFE and Viton double sealing.
4.Easy assembling design to be assembled.
5.Double layer cooling coils for improving condensers performance.
6.Supports OEM and ODM.
7.CE, ISO, UL, SGS certification.
8.1 year warranty and quality commitment.
9. PLC fully automatic is optional.
10.Explosion-proof system is optional.
Rotary Distiller: Advanced Solvent Recovery Solutions for Modern Laboratories
Our Rotary Distiller combines cutting-edge innovation with solid execution to meet your most requesting investigate needs. This accuracy instrument, too known as a rotational evaporator, conveys tender and effective dissolvable evacuation through inventive vacuum refining. Whether you're working in pharmaceutical R&D, botanical extraction, or nourishment science investigate, our item gives the exactness and unwavering quality your ventures request. With coordinates plan highlights and progressed temperature control, this hardware streamlines your workflow whereas ensuring heat-sensitive compounds from warm degradation.
Key Features & Benefits
Integrated Plan Excellence
Our revolving refining framework highlights a comprehensive coordinates plan. The have unit combines consistently with the radiator, chiller, and vacuum pump. This bound together approach rearranges your research facility setup and decreases hardware footprint.
The double-layer cooling coils upgrade condenser execution essentially. You'll accomplish prevalent dissolvable recuperation rates whereas keeping up steady operation. The PTFE and Viton twofold fixing framework guarantees amazing discuss snugness and tall vacuum performance.
Advanced Temperature Control
Precise temperature administration is significant for effective refining. Our framework offers remarkable control precision of ±1°C over the full working run. The water shower works from 20-100°C, whereas the discretionary oil shower expands the run to 180°C.
The Driven show gives clear, real-time observing of all basic parameters. You can effectively track temperature, turn speed, and timing capacities all through your process.
Safety & Security Features
Your research facility security is our need. The item incorporates comprehensive assurance frameworks:
- Motor overcurrent protection prevents equipment damage
- Earth leakage protection ensures operator safety
- Dry heating protection guards against overheating
- Overheat protection function maintains safe operation
- Optional explosion-proof system for hazardous applications
Technical Specifications
| Parameter | Specification |
|---|---|
| Evaporating Flask Volume | 5L |
| Speed Range | 20-180 RPM |
| Display Type | LED |
| Evaporation Capacity (75% Alcohol) | 2 L/h (Max) |
| Ultimate Vacuum | 9 mbar |
| Timer Function | 0-999 min |
| Water Bath Temperature | 20-100°C |
| Oil Bath Temperature | 20-180°C (Optional) |
| Temperature Control Accuracy | ±1°C |
| Heating Power | 2000W |
| Lifting Mode | Motorized |
| Lifting Stroke | 130mm |
| Voltage | 220V |
| Frequency | 50/60 Hz |
| Motor Type | Brushless DC motor |
| Heat Bath Coating | Teflon |
| Protection Class | IP20 |
| Dimensions (D×W×H) | 600×290×720mm |
| Ambient Temperature Range | 5-40°C |
| Ambient Humidity | ≤80% |
Applications Across Industries
Pharmaceutical & Biopharmaceutical Research
The precise vacuum control protects complex organic molecules during API concentration and isolation. Your valuable compounds remain stable throughout the distillation process.
Botanical Extraction Industry
Perfect for ethanol recovery in post-winterization processes. Industrial-scale operations achieve up to 95% solvent recovery, dramatically reducing operational costs.
Food Science & Molecular Gastronomy
Extract delicate flavors and aromas at low temperatures. Preserve the fresh profile of ingredients while creating concentrated essences.
Chemical Research & Analysis
Handle a wide range of solvents safely and efficiently. The chemical-resistant construction withstands demanding laboratory conditions.
Quality & Compliance
Our Rotary Distiller meets international quality standards including CE, ISO, UL, and SGS certifications. With 20 years of manufacturing experience, WIN LINK STAR TECHNOLOGY delivers proven reliability.
Every unit undergoes rigorous testing to ensure compliance with laboratory safety standards. The IP20 protection class provides appropriate environmental protection for standard laboratory conditions.
Service & Support
We stand behind our products with comprehensive support:
- 24-hour response time for technical inquiries
- 12-month warranty with quality commitment
- Complete installation documentation and guidance
- 12-hour video installation support for quick setup
- Multiple shipping options including sea, land, air, and express delivery
Customization Options
Understanding that different applications require specific solutions, we offer extensive customization capabilities:
- OEM/ODM services tailored to your requirements
- PLC fully automatic control for enhanced automation
- Explosion-proof systems for hazardous environments
- Custom configurations for specific country requirements
Our engineering team works closely with you to develop solutions that perfectly match your operational needs.
Why Choose WIN LINK STAR TECHNOLOGY?
With two decades of encounter in research facility hardware fabricating, we get it the basic significance of solid refining hardware. Our total autonomous supply framework and committed manufacturing plant guarantee steady quality and competitive pricing.
Our one-stop customized arrangements cover everything from introductory plan interview to progressing support back. This comprehensive approach makes a difference you make strides investigate productivity and quicken the change of inquire about accomplishments into viable applications.
Contact Us
Ready to enhance your laboratory's solvent recovery capabilities? Contact our technical experts today at info@winlinklab.com to discuss how our Rotary Distiller can optimize your research processes. Our team will help you select the perfect configuration for your specific applications and provide detailed technical specifications to support your decision-making process.
