3L Rotary Evaporator
2.Excellent air tightness, High vacuum performance.
3.PTFE and Viton double sealing.
4.Easy assembling design to be assembled.
5.Double layer cooling coils for improving condensers performance.
6.Supports OEM and ODM.
7.CE, ISO, UL, SGS certification.
8.1 year warranty and quality commitment.
9. PLC fully automatic is optional.
10.Explosion-proof system is optional.
3L Rotary Evaporator - Professional Laboratory Evaporation Solution
Our 3L Rotary Evaporator is the best of both worlds when it comes to volume and accuracy. Through evaporation under reduced pressure, this high-tech lab tool effectively removes solvents from samples. This makes it perfect for making medicines, extracting plants, and cleaning chemicals. When you buy something from WIN LINK STAR TECHNOLOGY, you get professional-grade efficiency backed by 20 years of experience making things. Our method keeps heat-sensitive compounds from breaking down and increases the rate at which solvents are recovered, which solves the most common problems that busy research labs face today.
Why Choose Our Rotary Evaporator?
You need equipment that works as hard as you do. Our system combines German engineering principles with practical laboratory functionality.
Integrated All-in-One Design
No more juggling multiple components. The host unit, heater, chiller, and vacuum pump work together seamlessly. This saves valuable bench space and simplifies your workflow.
Superior Sealing Technology
PTFE and Viton double sealing ensures excellent air tightness. You'll achieve high vacuum performance consistently. This means faster evaporation and better results every time.
Smart Temperature Control
Heat your samples from room temperature up to 180°C. Water-based heating provides ±1°C accuracy. Oil-based heating maintains ±3°C control. Your sensitive compounds stay protected.
Flexible Speed Adjustment
The brushless DC motor runs smoothly from 20 to 200 rpm. Rotate clockwise or counterclockwise as needed. This versatility handles everything from thin liquids to viscous solutions.
Enhanced Condensing Power
Double-layer cooling coils maximize condensation efficiency. Recover up to 1.56L of water per hour. Your solvents get captured, not wasted.
Technical Specifications
| Parameter | Specification |
|---|---|
| Evaporating Flask Volume | 50-3000mL (Thickened glass axis compatible with 3L flask) |
| Motor Type | Brushless DC motor |
| Speed Range | 20-200 rpm |
| Display Type | LED (speed, temperature, time) |
| Rotation Direction | Clockwise and counterclockwise |
| Heating Temperature Range | Room temp. to 180°C |
| Control Accuracy | Water: ±1°C / Oil: ±3°C |
| Evaporation Capacity | Max. 1.56L/h (H₂O) |
| Heating Power | 1200W |
| Lift Stroke | Manual 110mm + Auxiliary 100mm |
| Interval Time Setting | 1-999s |
| Dimensions | Main Unit: 440×320×450mm / Heating Bath: 300×300×240mm |
| Weight | Main Unit: 7kg / Heating Bath: 3kg |
| Operating Environment | Temperature: 5-40°C / Humidity: ≤80%RH |
| Protection Class | IP20 |
| USB Interface | Yes |
| Voltage/Frequency | 100-120/200-240V, 50/60Hz |
| Power Consumption | 1245W |
Key Advantages for Your Laboratory
Large LCD Display
Monitor all critical parameters at a glance. Temperature, speed, and time remain visible during operation. No more guesswork.
Overheating Protection
Built-in safety circuits prevent dry-running accidents. Your equipment and samples stay protected automatically.
Chemical Resistance
Borosilicate glass and PTFE components withstand aggressive solvents. Work confidently with acids, bases, and organic compounds.
Universal Compatibility
Our 3L Rotary Evaporator accepts standard glassware from all major manufacturers. Your existing flask collection works perfectly.
USB Connectivity
Download operation data for documentation and analysis. Track your processes digitally.
Customization & Global Support
Every lab has its own set of rules. We provide full ODM/OEM services that are suited to your needs. Our technical team can give you explosion-proof systems, full PLC automation, or custom voltage configurations.
International Standards Compliance
All units meet CE, ISO, UL, and ETL certifications. You get equipment that satisfies global quality benchmarks.
Fast Delivery Options
In-stock units ship immediately. We offer integrated shipping via sea, land, air, or express courier. Your equipment arrives quickly and safely.
24-Hour Responsive Service
Questions or concerns? Our technical team responds within 24 hours. You're never alone.
12-Month Warranty Coverage
Complete peace of mind with our comprehensive warranty. Systematic installation files included.
Video Installation Guidance
Need setup assistance? We provide video guidance within 12 hours of your request. Get running fast.
Is This the Right Choice for You?
The 3-liter capacity hits the sweet spot for many applications. You get more throughput than smaller 1L or 2L models without the footprint of 5L pilot-scale systems.
This system excels at:
- Pharmaceutical API purification
- Natural product extraction
- Chemical synthesis work
- University research projects
- Quality control laboratories
- Medium-batch production
Your samples deserve gentle, efficient processing. The rotating flask creates a thin film that maximizes surface area. Combined with reduced pressure, solvents evaporate at lower temperatures. Heat-sensitive compounds remain intact.
Built on 20 Years of Excellence
WIN LINK STAR TECHNOLOGY CO., LTD brings two decades of laboratory equipment manufacturing experience. Our complete independent supply system and factory ensure consistent quality and reliable delivery.
We serve research institutions, universities, and enterprise R&D departments worldwide. Our commitment goes beyond selling equipment - we partner with you for long-term success.
Ready to Upgrade Your Laboratory?
Invest in a 3L Rotary Evaporator that delivers reliable performance day after day. Our integrated design, superior materials, and comprehensive support make this the smart choice for serious researchers.
Contact our team today to discuss your specific requirements. We'll help you select the optimal configuration and accessories for your applications.
Get in touch: info@winlinklab.com
