10L Rotary Evaporator
2.Excellent air tightness, High vacuum performance.
3.PTFE and Viton double sealing.
4.Easy assembling design to be assembled.
5.Double layer cooling coils for improving condensers performance.
6.Supports OEM and ODM.
7.CE, ISO, UL, SGS certification.
8.1 year warranty and quality commitment.
9. PLC fully automatic is optional.
10.Explosion-proof system is optional.
High-Performance 10L Rotary Evaporator - Professional Laboratory Solution
Our proficient 10L Rotary Evaporator conveys remarkable execution for pilot-scale refining and extraction forms. This advanced instrument bridges the hole between benchtop investigate and mechanical generation, advertising predominant dissolvable recuperation rates surpassing 95%. Outlined for cannabis preparing, pharmaceutical amalgamation, and fine chemical applications, our rotating evaporator highlights progressed PTFE fixing innovation and exact temperature control. Culminate for research facilities requiring solid, nonstop operation with negligible support requirements.
Why Choose Our 10L Rotary Evaporator?
Superior Designing Design
Our rotating evaporator highlights an coordinates plan combining the have unit, radiator, chiller, and vacuum pump. This streamlined approach diminishes complexity whereas maximizing proficiency. The double-layer cooling coils upgrade condenser execution, guaranteeing quick dissolvable recuperation indeed amid expanded operations.
Advanced Fixing Technology
We've actualized PTFE and Viton twofold fixing instruments that ensure extraordinary vacuum execution. This dual-sealing framework keeps up vacuum levels down to 9mbar, avoiding vapor misfortune and guaranteeing steady comes about all through your refining process.
User-Friendly Operation
The motorized lifting framework with 200mm stroke gives smooth, exact control. Driven shows appear both temperature and revolution speed, making operation clear for professionals at any aptitude level. Clock usefulness permits robotized operation up to 999 minutes.
Technical Specifications
| Parameter | Specification |
|---|---|
| Evaporating Flask Volume | 10L |
| Speed Range | 20-130 RPM |
| Display Type | LED |
| Max Evaporation Capacity (75% Alcohol) | 3.8 L/h |
| Ultimate Vacuum | 9mbar |
| Temperature Range (Water Bath) | 20-100℃ |
| Temperature Range (Oil Bath) | 20-180℃ (Optional) |
| Temperature Control Accuracy | ±1℃ |
| Heating Power | 3000W |
| Lifting Mode | Motorized |
| Lifting Stroke | 200mm |
| Timer Range | 0-999 minutes |
| Voltage | 220V |
| Frequency | 50/60 Hz |
| Motor Type | Brushless DC Motor |
| Heat Bath Coating | Teflon |
| Dimensions (D×W×H) | 790×480×1130mm |
| Operating Temperature Range | 5-40℃ |
| Operating Humidity | ≤80% |
Key Applications
Cannabis and Hemp Processing
During winterization phases, this equipment serves as your primary ethanol recovery unit. The 10L capacity handles medium throughput volumes efficiently, making it ideal for operations where larger units are impractical.
Pharmaceutical Development
Concentrate Active Pharmaceutical Ingredients (APIs) while protecting thermolabile compounds from degradation. Precise temperature control safeguards your valuable biological products throughout the distillation process.
Fine Chemical Manufacturing
Handle crystallization preparation and solvent recovery in demanding laboratory environments. The chemical-resistant PTFE coating allows processing of corrosive materials without equipment degradation.
Advanced Safety Features
Your laboratory safety is our priority. Multiple protection systems include:
- Motor overcurrent protection
- Earth leakage protection
- Dry heating protection
- Overheat protection functions
- IP20 protection class rating
The brushless DC motor design eliminates sparks, making operation safer when handling volatile solvents. Emergency stop functionality provides immediate shutdown capabilities.
Quality and Compliance
We maintain rigorous quality standards with CE, ISO, UL, and ETL certifications. Our 20 years of manufacturing experience ensures each unit meets international laboratory standards. Every 10L Rotary Evaporator undergoes comprehensive testing including vacuum static holding tests and thermal uniformity checks.
Service and Support
Comprehensive Warranty
Every unit includes a 12-month warranty covering parts and labor. Our quality commitment extends beyond the warranty period with ongoing technical support.
Expert Installation Support
Receive complete installation documentation plus 12-hour video installation guidance from our technical team. Our 24-hour response service ensures minimal downtime.
Global Shipping
Choose from sea, land, air, or express shipping options. We maintain ready stock for immediate delivery, reducing your project timeline.
Customization Options
We offer ODM/OEM administrations custom-made to your particular necessities. Discretionary overhauls include:
- PLC completely programmed control systems
- Explosion-proof framework configurations
- Custom voltage and recurrence specifications
- Specialized coating options
Our designing group works closely with you to create arrangements coordinating your special research facility needs.
Why WIN Link STAR TECHNOLOGY?
As a proficient research facility gear provider with our claim plant, we control quality from fabricating through conveyance. Our total autonomous supply framework guarantees reliable accessibility and competitive pricing.
Our one-stop arrangement covers everything from introductory interview through establishment, commissioning, and continuous upkeep. This comprehensive approach makes a difference progress your inquire about productivity and quickens venture timelines.
Contact Us
Ready to enhance your laboratory's solvent recovery capabilities? Our 10L Rotary Evaporator delivers the performance, reliability, and safety features your operation demands.
Contact us today at info@winlinklab.com to discuss your specific requirements and receive a customized quote. Let our expertise help you select the perfect configuration for your laboratory applications.
