Your toughest mixing challenges become manageable with our high-torque motor system with Electric Overhead Stirrer. The stepless speed regulation provides precise control from 50 to 1100 rpm. Variable height adjustment accommodates different container sizes seamlessly.
Electric Overhead Stirrer
1.Max. Stirring Quantity[H2O]: 20L~70L
2.High reliability and outstanding performance
3.Wide range of speed from 50 to 2200rpm
4.LED screen for monitoring actual speed
5.Safety circuits allow for safe stop function in anti-stall or
overload conditions
6.Large chuck diameter for many shaft types
7.Brushless DC motor for long life, maintenance free and
explosion proof
8.Supports OEM and ODM.
9.CE, ISO, UL certification.
10.1 year warranty and quality commitment.
2.High reliability and outstanding performance
3.Wide range of speed from 50 to 2200rpm
4.LED screen for monitoring actual speed
5.Safety circuits allow for safe stop function in anti-stall or
overload conditions
6.Large chuck diameter for many shaft types
7.Brushless DC motor for long life, maintenance free and
explosion proof
8.Supports OEM and ODM.
9.CE, ISO, UL certification.
10.1 year warranty and quality commitment.
Electric Overhead Stirrer - Professional Laboratory Mixing Solution
The Electric Overhead Stirrer is your extreme arrangement for solid, capable blending. This proficient research facility gadget conveys remarkable execution for applications requiring vigorous torque and exact speed control. Not at all like conventional attractive stirrers that come up short with thick liquids, a item gives reliable comes about over assorted blending prerequisites. With progressed engine innovation and brilliantly control frameworks, this hardware guarantees ideal comes about each time.
Why Choose Our Electric Overhead Stirrer?
Superior Execution and Reliability
Our overhead stirrer conveys extraordinary blending capabilities with its brushless DC engine innovation. You get maintenance-free operation and expanded hardware life expectancy. The capable torque yield handles viscosities up to 100,000 mPa·s effortlessly.
The Driven show gives real-time checking of genuine speed and torque values. You can track your blending parameters accurately all through the whole prepare. Security circuits secure against over-burden conditions and guarantee secure operation.
Versatile Applications Across Industries
Pharmaceutical Research
- API synthesis and drug formulation
- Emulsion preparation for creams and ointments
- Vaccine and biological sample mixing
Chemical Manufacturing
- Polymer solution preparation
- Paint and coating production
- Resin mixing for industrial applications
Cosmetic Development
- Lotion and gel formulation
- Pigment dispersion
- Cream and foundation production
Technical Specifications
| Parameter | Specification |
|---|---|
| Max. Stirring Quantity [H₂O] | 70L |
| Speed Range | 50~1100rpm |
| Speed Display Accuracy | ±10rpm |
| Time Settings Range | 0-99h59min |
| Max. Torque | 300N·cm |
| Viscosity Max. | 100,000mPa·s |
| Weight | 3.2kg |
| Motor Type | Brushless DC motor |
| Voltage, Frequency | 100~240V, 50/60 Hz |
| Speed Display | LCD |
| Torque Display | LCD |
| Chuck Clamp Range Diameter | 0.5~10mm |
| Motor Input/Output Power | 180W/160W |
| Total Power | 200W |
| Dimensions [WxHxD] | 83 x 220 x 186mm |
| Protection Class | IP21 |
| Operating Temperature | 5~40℃, 80%RH |
| Data Interface | RS232 |
Key Advantages That Set Us Apart
Powerful Mixing Performance
Smart Control Features
Digital parameter control gives you real-time visibility into speed and torque values. The intelligent system maintains consistent performance even as viscosity changes during mixing. Multiple impeller compatibility ensures you find the perfect match for your specific application needs.
Chemical Resistance and Durability
Corrosion-resistant materials withstand aggressive chemicals and acidic environments. Your investment remains protected through demanding laboratory conditions. The robust construction ensures years of reliable service.
Quality Assurance and Standards
WIN LINK STAR TECHNOLOGY brings 20 years of manufacturing experience to every unit. Our products meet international quality standards including CE, ISO, UL, and ETL certifications.
We maintain strict quality control through comprehensive testing protocols. Each unit undergoes torque calibration, thermal endurance testing, and safety system verification before shipment.
Complete Service Support
Rapid Response Service
- 24-hour technical support response
- 12-month comprehensive warranty coverage
- Complete installation documentation provided
Global Shipping Solutions
Your orders ship immediately from our ready stock inventory. We offer integrated transportation options including sea freight, air cargo, and express delivery. Fast, reliable delivery gets your equipment operational quickly.
Customization Capabilities
Our ODM/OEM services adapt products to your specific requirements. Different countries and customer needs receive tailored solutions. Custom voltage configurations, specialized interfaces, and application-specific modifications are available.
Expert Installation and Training
Every purchase includes systematic installation files and comprehensive documentation. Our technical team provides video-guided installation support within 12 hours of request. You receive complete training on optimal operation procedures and maintenance practices.
Ready to Enhance Your Laboratory Efficiency?
The right mixing equipment transforms your research capabilities and productivity. Our Electric Overhead Stirrer combines proven reliability with advanced features that serious laboratories demand. Professional research institutions and quality control departments worldwide trust our solutions.
Email: info@winlinklab.com
Transform your mixing processes with professional-grade equipment that delivers consistent, reliable results. Your research deserves the precision and performance that only quality laboratory equipment can provide.
