Overhead Stirrer Lab Mixer
2.High reliability and outstanding performance
3.Wide range of speed from 50 to 2200rpm
4.LED screen for monitoring actual speed
5.Safety circuits allow for safe stop function in anti-stall or
overload conditions
6.Large chuck diameter for many shaft types
7.Brushless DC motor for long life, maintenance free and
explosion proof
8.Supports OEM and ODM.
9.CE, ISO, UL certification.
10.1 year warranty and quality commitment.
Overhead Stirrer Lab Mixer - Professional Laboratory Mixing Solution
When you require exact blending for high-viscosity arrangements, our Overhead Stirrer Lab Mixer conveys the control and control your research facility requests. Not at all like attractive stirrers that fall flat with thick media, this progressed blending framework handles viscosities up to 10,000 mPa·s with reliable torque conveyance. Our item highlights a brushless DC engine that gives maintenance-free operation and explosion-proof security for your most challenging applications. With 20 a long time of fabricating involvement, WIN Interface Innovation guarantees you get dependable hardware that meets CE, ISO, and UL worldwide standards.
What Makes Our Laboratory Mixing System Special?
Your investigate requires gear that adjusts to changing conditions. Our research facility stirrer highlights stepless speed control from 50 to 2200 RPM, permitting exact alteration for diverse stages of your prepare. The brushless engine innovation disposes of sparkles and diminishes upkeep needs.
The computerized LCD show appears real-time speed, torque, and over-burden assurance status. You can screen your blending parameters immediately without mystery. The flexible chuck obliges shaft breadths from 0.5 to 10mm, giving you adaptability with distinctive impeller types.
Safety circuits consequently halt operation amid over-burden conditions. This assurance avoids engine harm and guarantees reliable comes about. The IP21 security rating makes it reasonable for standard research facility situations.
Advanced Features for Professional Applications
Powerful Performance Specifications
| Parameter | Specification |
|---|---|
| Max. Stirring Quantity [H₂O] | 20L |
| Speed Range | 50~2200 RPM |
| Speed Display Accuracy | ±3 RPM |
| Max. Torque | 40 N·cm |
| Viscosity Maximum | 10,000 mPa·s |
| Motor Type | Brushless DC Motor |
| Voltage/Frequency | 100~240V, 50/60Hz |
| Power | 70W |
| Weight | 2.8kg |
| Dimensions [W×H×D] | 83×220×186mm |
| Chuck Clamp Range | 0.5~10mm |
| Protection Class | IP21 |
| Operating Temperature | 5~40℃ |
| Operating Humidity | 80% RH |
| Data Interface | RS232 |
Key Advantages
Your mixing challenges require smart solutions. Our equipment provides:
- Powerful stirring torque handles high-viscosity systems effortlessly
- Stepless speed regulation ensures stable and controllable mixing
- Adjustable paddle height works with various container sizes
- Chemical resistance suitable for acid-alkaline and complex media
- Digital parameter control with real-time speed and torque monitoring
- Multiple paddle compatibility meets diverse stirring requirements
Professional Applications
Pharmaceutical Manufacturing
Your pharmaceutical formulations need uniform mixing without contamination. This equipment handles emulsification of high-viscosity creams and ointments. The brushless motor prevents spark generation, ensuring safety with volatile compounds.
Polymer Research
During polymerization reactions, viscosity increases dramatically. Our Overhead Stirrer Lab Mixer maintains constant speed under changing loads. This consistency ensures proper molecular weight distribution and prevents reaction hot-spots.
Cosmetic Development
Creating stable cosmetic formulations requires precise dispersion control. The variable speed range allows gentle mixing for sensitive ingredients while providing enough power for thickener incorporation.
Chemical Synthesis
Complex chemical reactions often involve viscosity changes throughout the process. The real-time torque monitoring helps you track reaction progress and adjust parameters accordingly.
Quality and Reliability You Can Trust
WIN Connect Innovation brings 20 a long time of fabricating encounter to each unit. Our hardware meets universal measures counting CE, ISO, and UL certifications. We keep up total quality control through our free supply framework and factory.
Each unit experiences thorough testing some time recently shipment. Our quality commitment incorporates a 12-month guarantee with comprehensive back. We give 24-hour reaction time for specialized questions and 12-hour video establishment guidance.
Customization Capabilities
Your interesting prerequisites merit custom-made arrangements. We offer ODM and OEM administrations to meet particular nation directions or application needs. Our building group works with you to adjust determinations, make custom interfacing, or create specialized adornments.
Shipping and Support
We maintain ready stock for immediate delivery. Our integrated transportation system includes sea, land, air, and express shipping options. This flexibility ensures you receive your equipment quickly regardless of location.
Our support includes:
- System installation files and documentation
- Video-guided setup assistance within 12 hours
- Technical support with 24-hour response time
- 12-month comprehensive warranty coverage
Get Started Today
Transform your laboratory mixing capabilities with professional equipment designed for demanding applications. Our Overhead Stirrer Lab Mixer combines German engineering principles with practical functionality your research requires.
Ready to upgrade your mixing processes? Contact our technical team at info@winlinklab.com for detailed specifications, customization options, or application guidance. We help you select the right configuration for your specific requirements.
