Rosemount High Precision 2700 Flow Meter
2. Using MVD digital processing technology, it can receive performance diagnosis in pinch applications and air-filled batch applications.
3. It reduces the wiring cost and can be easily and quickly installed.
4. Concentration and net flow measurements are available without additional instrumentation.
5. Obtained SIL2 and SIL3 accreditation and certification for trade handover.
6. Verify the health of the sensor online with true field verification while the process is running and without the use of auxiliary references.
7. With the WirelessHART solution, you can obtain additional diagnostic and process information without additional wiring costs.
8. Robust Class 1 classification/Zone 1 housing and optional local operator interface for easy flow meter operation.
Rosemount High Precision 2700 Flow Meter - Advanced Digital Flow Measurement Solution
The Rosemount High Precision 2700 Flow Meter delivers exceptional accuracy with its revolutionary MVD technology. This advanced multivariable transmitter system transforms how you measure mass flow, density, temperature, and volume. Unlike traditional analog meters, it digitizes sensor signals at the source for superior stability and reliability. WIN LINK STAR TECHNOLOGY brings you this cutting-edge solution with comprehensive support.
Product specification
1. Output variables:
• Mass and volume flow
• Net product content/flow
• Temperature
• Density
• Concentration
2. Local Display panel: Standard user interface with 2-line LCD display
• Two optical buttons for local operation
• Glass or plastic dial options
3. Power supply: AC/DC input automatic switching, automatic identification of power supply voltage
85 to 265 VAC, 50/60 Hz, typical value 6 W, maximum 11 W
•18 to 100 VDC, typical value 6 W, maximum 11 W
• In accordance with EN 61010-1 (IEC61010-1) revised version 2 of the low-voltage equipment Specification 2006/95/EC, installation (overvoltage) Category II, pollution level 2
4. Input/output signal (analog output option)
• Non-intrinsic safety
• One active 4-20 mA output
• One active frequency output
• Frequency output can be configured as discrete output
5. Input/output signal (configurable input/output options)
• Non-intrinsic safety
• One or two active 4-20 mA outputs
• One or two active/passive frequency outputs
• One or two active/passive discrete outputs
• One discrete input
6. Input/output signal (intrinsic safety option)
• Intrinsically safe
• One passive 4-20 mA output
• One passive frequency output
• Frequency output can be configured as discrete output
7. Input/output signals (Foundation fieldbus option)
• Intrinsic safety (or optional non-flammable)
• All the way Foundation fieldbus H1 output
8. Input/output signal (PROFIBUS-PA option)
• Intrinsically safe
• One PROFIBUS-PA output
9. HART/WirelessHART
• The Bell 202 signal is superimposed on the primary milliamp output
•WirelessHART is available via THUM adapter
HART communication is not available for Foundation Fieldbus and PROFIBUS-PA transmitter versions
6. Installation options Field installation
• Integrated mount to high precision F, R or H series sensors
• Split-mounted to any 4-wire or 9-wire high-precision Coriolis sensor
7. Application type
• Continuous process control
• Trade transfer measurement
• Two-phase flow/gas bearing
• Instrument online self-calibration
• SIS certified
8. Hazard certification
• Class I, Zone 1
• Class I, Zone 2
• Zone 1
• Zone 2
Technical Specifications
| Parameter | Specification |
|---|---|
| Flow Accuracy | ±0.05% (depending on sensor) |
| Density Accuracy | Up to ±0.0002 g/cc |
| Update Rate | Up to 100 Hz |
| Output Options | 4-20mA, Frequency/Pulse, HART, Modbus RS-485 |
| Housing Rating | NEMA 4X (IP66) |
| Safety Certification | SIL 2/SIL 3 capable |
| Hazardous Area Rating | Class I Division 1/Zone 1 |
| Mounting Options | Integral or Remote |
| Wiring | 4-wire architecture |
| Temperature Range | Process dependent on sensor selection |
Applications Across Industries
Oil & Gas Operations
Your custody transfer applications demand absolute accuracy. This meter handles LACT units with precision despite fluid viscosity changes or entrained gas presence. You get reliable fiscal metering that protects your bottom line.
Chemical Processing
Precise chemical dosing becomes effortless with rapid digital response times. The robust housing protects electronics in corrosive environments. Your expensive additives are measured accurately every time.
Food & Beverage Manufacturing
Monitor concentration levels while measuring flow simultaneously. The system withstands CIP thermal shocks without measurement drift. You maintain sanitary compliance with consistent performance.
Pharmaceutical Production
Critical batch processes require unwavering precision. The Rosemount High Precision 2700 Flow Meter delivers repeatable measurements for your quality control requirements.
Frequently Asked Questions
How does MVD innovation make strides performance?
MVD digitizes crude sensor signals promptly, utilizing progressed DSP to channel vibration and gas clamor effectively.
Can this meter handle safety-critical applications?
Yes, SIL 2 capability (SIL 3 in repetitive arrangements) makes it appropriate for Security Instruments Systems.
What almost gas bubbles in fluid lines?
The framework keeps up estimation amid two-phase stream occasions utilizing versatile picks up, in spite of the fact that precision details may incidentally widen.
Does it require visit recalibration?
Smart Meter Confirmation permits comprehensive wellbeing checks in-line, amplifying calibration interims altogether.
Get Your Rosemount High Precision 2700 Flow Meter Today
Transform your flow measurement capabilities with proven technology. The Rosemount High Precision 2700 Flow Meter combines accuracy, reliability, and advanced diagnostics in one robust package. Your processes deserve the precision that only digital MVD technology provides.
Contact our experts at info@winlinklab.com for technical consultation and customized solutions. Let us help you improve your measurement accuracy and operational efficiency with professional support you can trust.
